EUS1800 Common Rail Diesel Fuel EUI EUP Injector Pump Tester

EUS1800 Common Rail Diesel Fuel EUI EUP Injector Pump Tester
Product Description:
Test an EUI or an EUP on a conventional pump test bench. Offer adapter kits for most EUIs and EUPs on the world market.
The EUS1800 repair tester is designed to perform repair tests for different type of Electronic Unit Injectors (EUI) and Electronic.Unit Pumps(EUP). The tester consists of a mechanical cam box (CB-1000) with customer specified EUI/EUP adapter kits and a modular designed electronic controller (EU-4000). The CB-1000 cam box is driven by a standard high pressure fuel injection pump test bench.
The EUS1800 controller is modular designed to fit customer's applications for testing various EUI.s/EUPs.

Production Features:
1. Support all types of EUI/EUP tests (test plan can be added and edited) (Including electromagnetic, piezoelectric, double pulse M11, double solenoid valve dephi E3，HPI X15,QSK60)
2. Support three kinds of cam signal input of Hall, magnetoelectric and encoder;
3. Support BIP signal input and display BIP value(BIP sensor and adapter required);
4. Support flow sensor signal input and display flow value(Judge whether the flow is qualified or not, and support common flowmeter models);
5. Injector resistance, inductance or capacitance can be measured (standard data can be added);
6. It can drive an electromagnetic injector or a piezoelectric injector, (Built-in more than 3,500 standard data);
7. IQA coding of common rail injector can be generated (optional).
8. Common rail injector opening pressure/opening pulse width test, single injection test;
9. AHE lift test of common rail injector;
10. It can drive CAT HEUI injector (built-in test plan);
11. The drive current and voltage of the injector are adjustable;
12. The drive waveform can be displayed (the same as the waveform measured by the oscilloscope);
13. More than a dozen language interfaces are available;
14. It can be remotely assisted on the Internet and can be upgraded with one key;
15. Standard 2U chassis design, high-grade aluminum alloy panel, with fixed ears, easy to fix to the cabinet;
